V-TR0001
Serialized engraving tag, indicated for application in the vulcanization of tires, in this way it can be used for control and verification of product registration (manufacturer, warranty period, entry/exit date, etc.).
Technical Features
Dimensions (LxWxH): 90x27x0.5mm.Reading Frequency: 902-928MHzTID: Not Changeable.EPC: 96 bits.Data retention: 50 years.Rewrites: 100,000.Operating Temperature: -25° to 180°C.Fixing: vulcanization.Optional: Serialized recording.
| Material | Reading distance |
|---|---|
 Metal | 0.20m |
 Wood | 5m |
 Plastic | 6m |
 Paper | 5m |
 Organic | 1.25m |
Tests performed with ViaondaRFID M-ID40 reader + 7.5dBic Antenna + 2 meter 50ohm cable
Warranty
- Full 1 year warranty for manufacturing defects.
Lifespan
- Considering that the tag has not been subjected to impacts, falls or incorrect handling, it has an indefinite useful life, as long as it is used for the purpose for which each model was designed.
Dispose and Recycle
- The tags are made of plastic material, paper, adhesive (water-based or solvent-based), microchip and aluminum inlay (antenna). These materials are recyclable and can be delivered to any collection point (Ecoponto) or delivered to recycling companies and cooperatives. If there is no Ecopoint near you, you can send us the material with the proper identification of MATERIAL FOR DISPOSAL and we will send it correctly for each type of material that can be recycled.
